VIKING MTM 200 PRO Semi-automatic welding machine
Russia
China
Description
The VIKING MTM 200 PRO universal welding semi-automatic (4 In 1) is a technological welding inverter based on a high-performance 32-bit processor designed for professional welding of all types of metals.
The multifunctional device operates in SYN MIG, MMA, DC TIG, DC PULSE TIG, SPOT modes. designed for manual arc welding with a coated electrode, semi-automatic welding in a protective gas environment and argon arc welding with a tungsten electrode. This welding inverter is suitable for those who want to master all three main welding methods at once.
Welding modes
TIG mode - Argon arc welding with a non-melting tungsten electrode for welding carbon, stainless steels and their alloys.
MMA mode - For working with piece electrodes with different types of coating: acidic, basic, rutile.
MIG/MAG mode - For welding carbon steels, chromium-nickel stainless steels, aluminum and its alloys, excellent weld formation, and full arc control, high accuracy and repeatability of welding results.
Features
- of the model 220 V mains operation
- Compact design
- Built-in wire feed mechanism
- The presence of an oscillator for contactless ignition in TIG mode
- Smooth adjustment of the wire feed speed
- Display
- Low power consumption
- Overheating protection
Specifications:
- Afterburner arc 0-150%
- Hot strat 0-150%
- MIG wire 0.6, 0.8, 1.0.
- Base current 10-100%
- Pulse TIG: Pulse rate 0.2-500Hz
- Elementary/Final current 10-100%
- Spot welding — Yes
- EFFICIENCY 85%
- IP-23
Equipment
- Inverter apparatus
- Welding torch MIG-15AK, 3m
- Welding torch TIG-17, 4m
- Spare parts kit for MIG/TIG burner
- Cable with an electrode holder of 2 m
- Cable with grounding terminal, 2 m
- User Manual
Characteristics
General Specifications
China
Russia
Dimensions of packaged product
Specifications
Indicates the degree of protection of the device body from penetration of solid objects and moisture.
-
IP21 provides protection against large particles and vertically falling droplets (suitable only for dry, indoor areas).
- IP23 means protection against oblique rain (splashes at an angle up to 60°), which allows safe operation of the device on open construction sites.
Indicates the degree of protection of the device body from penetration of solid objects and moisture.
-
IP21 provides protection against large particles and vertically falling droplets (suitable only for dry, indoor areas).
- IP23 means protection against oblique rain (splashes at an angle up to 60°), which allows safe operation of the device on open construction sites.
The maximum electrical power consumption of the equipment at peak loads. This parameter is critical for selecting the cable cross-section and the nominal value of the protection devices. For a garage and a 220V household network, the limit is 5-7 kW. More powerful industrial installations necessarily require a three-phase 380V connection.
The maximum electrical power consumption of the equipment at peak loads. This parameter is critical for selecting the cable cross-section and the nominal value of the protection devices. For a garage and a 220V household network, the limit is 5-7 kW. More powerful industrial installations necessarily require a three-phase 380V connection.
The voltage at the terminals is switched on before the arc is ignited. The higher this value (closer to 80-100 V), the easier and faster the initial ignition occurs, and the more stable the arc burns (especially on rusty metal or with base-coated electrodes). Low values are typical for devices with a safe voltage reduction system (VRD).
The voltage at the terminals is switched on before the arc is ignited. The higher this value (closer to 80-100 V), the easier and faster the initial ignition occurs, and the more stable the arc burns (especially on rusty metal or with base-coated electrodes). Low values are typical for devices with a safe voltage reduction system (VRD).
The duration of activation (PV). This is the ratio of continuous operation time to cooling time in a 10-minute cycle. The value "200/40" means that at a current of 200 A, the device cooks for 4 minutes, and then cools down for 6 minutes. For intensive production and production lines, models with PV from 60% to 100% at operating currents should be selected.
The duration of activation (PV). This is the ratio of continuous operation time to cooling time in a 10-minute cycle. The value "200/40" means that at a current of 200 A, the device cooks for 4 minutes, and then cools down for 6 minutes. For intensive production and production lines, models with PV from 60% to 100% at operating currents should be selected.
Maximum current for manual arc welding. Provides the ability to work with thick electrodes. The high current reserve allows the device to operate for a long time at medium currents without overheating.
Maximum current for manual arc welding. Provides the ability to work with thick electrodes. The high current reserve allows the device to operate for a long time at medium currents without overheating.
Minimum current strength for manual welding. It is important when using the thinnest electrodes (for welding elements 1-2 mm thick) and for maintaining a stable arc at low currents.
Minimum current strength for manual welding. It is important when using the thinnest electrodes (for welding elements 1-2 mm thick) and for maintaining a stable arc at low currents.
The lower threshold of current regulation. The minimum values (10-30 A) are necessary for jewelry work, restoration, welding of tinplate and automobile panels without the risk of their warping or formation of through holes.
The lower threshold of current regulation. The minimum values (10-30 A) are necessary for jewelry work, restoration, welding of tinplate and automobile panels without the risk of their warping or formation of through holes.
Maximum current in semi-automatic mode. It directly affects the maximum thickness of the metal being melted in one pass. 160-200 A is sufficient for household needs, and devices with a current of 300 to 500 A are required for welding heavy steel structures in production.
Maximum current in semi-automatic mode. It directly affects the maximum thickness of the metal being melted in one pass. 160-200 A is sufficient for household needs, and devices with a current of 300 to 500 A are required for welding heavy steel structures in production.
Lower current limit in TIG mode. Values from 5 A make it possible to weld capillary tubes, the thinnest foil, and repair miniature parts where the slightest overheating leads to edge destruction.
Lower current limit in TIG mode. Values from 5 A make it possible to weld capillary tubes, the thinnest foil, and repair miniature parts where the slightest overheating leads to edge destruction.
Peak power for argon arc welding. High current is required when working with heat-intensive parts (for example, massive aluminum or steel assemblies) in order to quickly form a welding bath.
Peak power for argon arc welding. High current is required when working with heat-intensive parts (for example, massive aluminum or steel assemblies) in order to quickly form a welding bath.
