GS545 radial drilling machine
Belarus
Belarus
Description
The machine is designed for processing holes in small, medium and large parts at an angle of ± 45 ° in the plane of the sleeve.
Drilling, reaming, countersinking, deployment, threading in steel, cast iron and other metals and alloys can be performed on the machine,except for those alloys whose processing on the machine can lead to a fire hazard situation.
Technical characteristics of the machine
Name of the parameter |
Parameter value |
The largest drilling diameter in steel 45 GOST1050, mm |
45 |
The largest diameter of the thread to be cut (Steel 45) |
M24 |
Spindle reach (distance from the spindle axis to the forming column, measured in a plane parallel to the sleeve guides and passing through the column axis), mm: |
|
the largest, not less |
1100 |
the smallest, no more |
320 |
Drilling radius (distance from spindle axis to column axis), mm: |
|
maximum, not less |
1220 |
the smallest, no more |
470 |
Distance from the lower end of the spindle to the base mirror, mm: |
|
maximum, not less |
1250 |
the smallest, no more (below the plate mirror) |
Minus 60 |
Number of spindle speed steps |
12 |
Spindle speed, rpm |
45, 63, 90, 125, 180, 250, 355,500, 710, 1000, 1400, 2000 |
Number of stages of mechanical feedings of the spindle |
4 |
Mechanical feedings of the spindle, mm/rev |
0.056; 0.1; 0.18; 0.32 |
Maximum torque on the spindle, N·m |
180 |
Maximum feed force, kN |
12 |
Main motion drive power, kW |
3 |
Overall dimensions of the machine, mm: |
|
length |
1800 |
width |
925 |
height |
2260 |
The weight of the machine without accessories supplied for a fee, kg, no more |
1480 |
Column |
|
Column diameter, mm |
220 |
Sleeve |
|
The largest vertical movement of the sleeve along the column, mm |
1060 |
The total angle of rotation of the sleeve around the axis of the column (vertical axis). |
360º |
The clamp on the column |
is manual |
Drilling head |
|
The largest stroke along the sleeve guides, mm |
780 |
The total angle of rotation of the drill head around the horizontal axis. |
±45º |
The head clamp on the sleeve guides |
is manual |
Spindle |
|
Spindle stroke, mm: maximum |
250 |
per 1 turn of the steering wheel |
100, 48 |
by 1 division of the limb |
1 |
for knocking out the tool, no more |
15 |
Spindle inner cone |
Morse Code 4 AT6 GOST 25557 |
Foundation plate |
|
Working surface size, mm: |
|
width |
760±3 |
length (up to column flange) |
1250±5 |
height |
206±2 |
Number of slots |
3 |
Slot width according to GOST 1574, mm. |
18 |
Distance between slots, mm |
160 |
Rectangular removable table |
|
Working surface size, mm: |
|
horizontal |
360x500 |
vertical |
400x500 |
Slot width, mm |
14H12 |
Distance between slots, mm |
100 |
Number of slots on the surface: |
|
horizontal |
3 |
vertical |
3 |
