Thermal imager construction Ermenrich Seek TV50
Russia
China
Description
With the Ermenrich Seek TV50 construction thermal imager, malfunctions accompanied by a local temperature rise can be quickly detected. These may be places where contacts in electrical appliances are heated, places where heat is lost in building facades, in heating and hot water supply systems. The thermal imager can also detect harmful rodents (mice and rats). The device is sensitive in the temperature range from -20 to +400 °C. It is powered by a 2600 mAh lithium battery with charging via a USB cable (included).
Detection is performed using a thermal imaging sensor (resolution 32x32 pixels) and a camera (resolution 2 megapixels). The device has a photo capture function, photos are saved in the * format.bmp to a 16 GB memory card (included). Photos can be transferred to a smartphone or computer via a microUSB cable.
The image can be displayed in 4 modes: optical (visible light), infrared or in one of two mixed modes (optical + infrared). In addition, there are seven color options (palettes). The observed objects are visualized on a color LCD display with a resolution of 320x240 pixels. To control the device, 4 buttons are used under the display and one on the handle of the thermal imager. During operation, the device is held in the hands, a tripod mount is not provided in this model.
Main Features:
- 32x32 pixels thermal imaging sensor, 2 Megapixel camera
- 4 visualization modes, including combining optical and infrared images
- 7 color palettes
- Temperature measurement in the range from -20 to +400 °C
- Taking photos and saving to a 16 GB memory card
- Battery capacity of 2600 mAh
Package contents:
- Thermal imager
- 16 GB memory card
- microUSB Cable
- Case
- Operating instructions and warranty card
Specifications:
- EAN: 5905555021560
- Thermal Imager Type: Manual
- Spectral range, µm: 8-14
- Frame rate: less than9
- Temperature measurement range, °C: -20 — 400
- Temperature error, %: resolution: 0.1 °C, accuracy: 0...+400 °C: ±1.8 °C; -20... -0.9 °C: ±3 °C
- Temperature sensitivity (NETD), mK: 150
- Color palettes: hot white, hot red, hot black, red iron, lava, rainbow, cool color
- Field of view angle (horizontal)x(vertical), °: 33 (horizontal), 18 mrad (instant)
- Fusion of optical and thermal images: +
- Display: 2.4” TFT, LCD
- Display resolution, pixels: 320x240
- Resolution of the microbolometric matrix, pixels: 32x32
- Operating modes: IR image, IR edge display, visual image, fusion of IR and visual image
- Power supply: 2600mAh, 3.7V, charging via microUSB cable (included)
- Maximum impact load, g: falling from a height of up to 1 meter
- Operating temperature range, °C: -10 — 45
- Built-in recorder: Yes
- Memory: 16 GB memory card (included)
- Photo file format: *.bmp
- Interface connectors: microUSB
- Case/Case/Bag included: Carrying case
- Optional: response time: 150 ms, low battery indicator, camera resolution: 2 megapixels, adjustable emissivity from 0.1 to 0.99, auto-off function
Characteristics
General Specifications
China
Russia
Dimensions of packaged product
Specifications
- What it affects: When going beyond the specified limits (for example, in severe frost or in a hot workshop), the screen may start to "slow down", the battery will run out in a matter of minutes, and the measurement error will increase dramatically.
- For outdoor work in winter: Choose models with a lower threshold of -20°C or -30°C. Conventional appliances (from -10°C) can switch off at the most crucial moment.
- To inspect roofs in summer or industrial facilities: Pay attention to the upper limit (+50°C or +60°C), as the device body heats up in the sun or from the equipment.
- What it affects: When going beyond the specified limits (for example, in severe frost or in a hot workshop), the screen may start to "slow down", the battery will run out in a matter of minutes, and the measurement error will increase dramatically.
- For outdoor work in winter: Choose models with a lower threshold of -20°C or -30°C. Conventional appliances (from -10°C) can switch off at the most crucial moment.
- To inspect roofs in summer or industrial facilities: Pay attention to the upper limit (+50°C or +60°C), as the device body heats up in the sun or from the equipment.
Lower threshold:
- Usually -10...-20 °C: Important for finding heat leaks in winter, checking the quality of thermal insulation of walls and windows, and identifying "cold bridges" outside the building.
Upper threshold:
- Up to +120...+150 °C: Sufficient for checking heating systems, underfloor heating and finding blockages in radiators.
- Up to +300...+400 °C: Necessary for diagnostics of electrical panels, circuit breakers, loaded bearings and industrial equipment.
Lower threshold:
- Usually -10...-20 °C: Important for finding heat leaks in winter, checking the quality of thermal insulation of walls and windows, and identifying "cold bridges" outside the building.
Upper threshold:
- Up to +120...+150 °C: Sufficient for checking heating systems, underfloor heating and finding blockages in radiators.
- Up to +300...+400 °C: Necessary for diagnostics of electrical panels, circuit breakers, loaded bearings and industrial equipment.
