Self-propelled trolley Shtapler QDCX 15 (S)
Russia
China
Description
The Shtapler QDCX 15 (S) self-propelled electric trolley with a lifting capacity of 1.5 tons is designed for transporting europallets at wholesale bases, warehouses, logistics centers and stores. The trolley is equipped with an electric motor, a lead-acid battery and polyurethane wheels that are suitable for tiled floors. The adjustment function of the suspension rods ensures the durability of the Shtapler QDCX 15(S) trolley.
Technical Characteristics:
- Type of equipment electric trolley leash (accompanied)
Basic parameters
- Load capacity, kg 1500
Fork sizes
- Fork length, mm 1150
- Fork width, mm 560
- Width of the 1st fork, mm 150
- Width between forks, mm 260
Basic sizes
- Lifting height, mm 85
- Lifting height, mm 200
- Frame height, mm 600
- Height with handle, mm 1195
Other sizes
- Metal thickness, mm 3-21
- Load center, mm 600
- Turning radius, mm 1352
- Ground clearance, mm 35
- Aisle width with pallet (800x1200mm), mm 1881
Wheels
- Steering wheel material polyurethane
- Steering wheel size, mm 210x70
- The material of the support rollers is polyurethane
- The size of the support rollers, mm 80x60
- The material of the support wheels is polyurethane
- The size of the support wheels, mm 80x60
- The total number of wheels/rollers is 5
Features
- Electric movement
- The lift is electric
- There is no operator platform
- Brake yes
Electric motor
- Lifting engine power, kW 0.8
- The power of the movement engine, kW 0.75
- Lifting speed with load, mm/s 22
- Lifting speed without load, mm/s 25
- The speed of movement with cargo, km/h 4.2
- The speed of movement without cargo, km/h 4.5
- The overcome angle of inclination with the load, %5
- The overcome angle of inclination without load, %16
- Time to complete lifting without load, 8-10 seconds
Battery
- Battery type lead-acid
- Battery, V/Ah 24/65
- Quick-release battery yes
- Memory type built-in
Origin
- 12 months warranty
- Manufacturer SHTAPLER INDUSTRIES CO., LTD
- Country of manufacture China
- Importer of BELAPEX LLC
Equipment
- Complete set of instructions, charger, trolley
- Packaging cardboard
Dimensions and weight of the product assembly
- Total length, mm 1710
- Total width, mm 560
- Total height, mm 1230
- Net weight, kg 189
Dimensions and weight of the product in the package
- Package length, mm 1710
- Package width, mm 560
- Package height, mm 1230
- Gross weight, kg 190
