Advantages of CADVI tillers
- Versatility – the equipment is suitable for plowing, cultivating, planting and harvesting potatoes, mowing grass, snow removal and cargo transportation.
- Reliability – tillers work effectively on difficult soils, slopes and inconveniences.
- Efficiency – engines (Lifan, Honda, Briggs & Stratton) consume less than 2 liters/hour, providing high performance.
- Compactness – the equipment is easily transported in the trunk of the car.
- Accessibility – low maintenance and repair costs.
Popular models
Oka motor block
It has been produced since 1991 and remains one of the most sought-after models. It has an optimal price-quality ratio. The possibility of using a wide range of trailed and mounted equipment: plough, hoe, cultivator cutters, potato digger, potato planter, rotary mower, ground hooks, truck, snow plow, brush, shovel blade.
Features:
- Transmission type Chain gearbox, V-belt transmission
- Overall dimensions in the package, mm. 910x560x1114
- Package weight, kg. not more than 100
- Ground clearance, mm 140
- Transport track, mm 310
Speed of movement
- 1 gear — 3.6 km/h,
- 2nd gear — 9 km/h
Engine parameters
- Lifan 168F-2 engine
- Power 6.5 hp
- The fuel tank capacity is 3.6 liters.
- Overall dimensions 313 mm/376 mm/335 mm
- Dry weight 16 kg
- The maximum torque is 11×3000 Nm / rpm.
Ugra motor block
Manufactured since 2009, it is equipped with a gear gearbox and a disc clutch. In combination with attachments, it can perform a diverse range of jobs: till the soil, mow, dig and plant potatoes, transport cargo, and remove snow. It has two power take-off shafts, which allows you to connect a wide range of additional mounted guns.
Features:
- Transmission type Manual transmission, gear box
- Overall dimensions in the package, mm 960x690x1151
- Package weight, kg 90
- Ground clearance 150 mm
- Transport track 405 mm
Speed of movement
- 3 front (3,6 / 5,8 / 8,5 km/h)
- 1 rear 2.2 km/h
Engine parameters
- Lifan 168F-2 engine
- Power 6.5 hp
- The fuel tank capacity is 3.6 liters.
- Overall dimensions are 313 mm / 376 mm/335 mm.
- Dry weight 16 kg
- The maximum torque is 11×3000 Nm / rpm.
Avangard motor block
Lightweight model (since 2016) with innovative weight distribution for stability.The innovative weighing scheme gives the engine block stability and stability during operation, even with low gasoline quality.
The tillerblock is designed to perform agricultural work on household plots, in gardens and vegetable gardens for individual use – not on an industrial scale!
Features:
- Transmission type Gear chain, V-belt transmission
- Overall dimensions in the package, mm 910x630x1114
- Package weight, kg not more than 90
- Ground clearance 145 mm
- Transport track 350 mm
Speed of movement
- 2 front wheels (3.8 / 5.3 km/h)
- 1 rear 2.9 km/h
Engine parameters
- Lifan 168F-2 engine
- Power 6.5 hp
- Fuel tank capacity 3.6 liters.
- Overall dimensions are 313 mm / 376 mm/335 mm.
- Dry weight 16 kg
- The maximum torque is 11×3000 Nm / rpm.
Cadvi tillers are a time–tested technique that ensures high productivity at minimal cost. A wide range of models allows you to choose the equipment for any task.
