The company Uglichkabel presents the cable NYM, designed for reliable stationary electrical installation in the industrial and residential sectors. The cable is of high quality, conforming to the German standard DIN VDE 0250-204, and easy to install due to the multi-colored insulation of the cores and ease of cutting.
Scope of application
NYM cables are used for the transmission and distribution of electrical energy in stationary installations at a voltage of up to 0.66 kV and a frequency of 50 Hz.
- Open and hidden indoor installation
- Laying on top of plaster, in it and under it
- Use in brickwork and concrete (except bulk and stamped)
- Laying in pipes (steel and plastic), cable ducts and ducts
Important:Outdoor use is possible only in the absence of direct sunlight exposure.
Advantages of the NYM cable
- High quality according to DIN VDE 0250-204
- Copper cores and reliable PVC insulation
- Convenient and quick installation (multi-colored insulation, easy cutting)
- The outer shell and filling protect the cores during laying
- Does not contain lead
- The coils are packed in shrink wrap for safety
Technical specifications
|
Parameter
|
Value
|
|
Core material
|
Copper
|
|
Number of veins
|
1–5
|
|
Isolation
|
PVC plastic
|
|
Completion
|
Non-vulcanized rubber compound
|
|
Outer shell
|
PVC plastic
|
|
Rated voltage
|
up to 0.66 kV
|
|
Frequency
|
50 Hz
|
|
Operating temperature range
|
from -50°C to +50°C
|
|
Minimum temperature of the gasket without heating
|
−15°C
|
|
Long-term allowable core heating temperature
|
+70°C
|
|
Minimum bending radius
|
7.5 × D (outer diameter of the cable)
|
Types of execution
- NYM-J is a cable with a green-yellow grounding core
- NYM-O — cable without grounding conductor (only NYM-O is available in 2-core version)
